Description
Product Description
The Simply Conserve 10" Field-Adjustable Parking Garage/Canopy LED is designed for overhead lighting in areas where visibility, coverage, and durability are all important. Its wide 155° beam angle helps spread light evenly across parking bays, covered walkways, service areas, gas station-style canopies, loading zones, and other ceiling-mounted commercial applications.
Onboard switches allow installers to choose 40W, 60W, or 70W and select 3000K, 4000K, or 5000K during installation, making one fixture adaptable across different ceiling heights, brightness needs, and exterior lighting preferences. The compact 10" form factor keeps the fixture low-profile, while the IP65 wet-location rating supports use in exposed or demanding environments. With 0–10V dimming, up to 8400 lumens, 120 LPW efficacy, and a 50,000-hour rated life, this canopy fixture is built for parking and covered-area lighting that needs broad coverage without overcomplicating the installation.
Key Features
-
Versatile Installation
Designed to fit seamlessly into both retrofit upgrades and new construction projects. -
Adjustable Wattage & CCT
Field‑selectable power consumption and color temperature provide flexible performance for a variety of applications. -
Long-Lasting Performance
An L70‑rated 50,000‑hour lifetime for commercial environments. -
Controlled, Even Illumination
0–10V dimming and a wide 155° beam angle work together to deliver smooth, uniform lighting across large areas. -
Built for Tough Environments
Wet‑location and IP65 protection ensure reliable performance in exposed or demanding areas.
Product Specifications:
- Manufacturer Code: L40/70-PG10-30/50-120/277V-D-ADJ
- Brand: Simply Conserve
- Product Type: Field-Adjustable Parking Garage/Canopy LED
- Fixture Type: Parking Garage / Canopy Light
- Fixture Size: 10"
- Wattage: Field selectable 40W / 60W / 70W
- Lumens: 4800 / 7200 / 8400
- Color Temperature: Field selectable 3000K / 4000K / 5000K
- Efficacy: 120 LPW
- CRI: ≥80
- Voltage: 120–277V
- Dimming: 0–10V dimmable
- Beam Angle: 155°
- Location Rating: Wet rated
- Ingress Protection: IP65
- Installation Type: Retrofit or new construction
- Rated Life: 50,000 hours, L70 rated
- Product Dimensions: 10.1" L x 10.1" W x 4.2" H
- Case Quantity: 4
- Case Dimensions: 23.0" L x 13.0" W x 12.5" H
- Warranty: 5-year limited warranty
- Certifications / Compliance: DLC Listed, cULus Listed
